Specifications:
Recommended Use |
Indoor |
Operating System |
Android 4.4.2, KitKat |
Processor |
Cortex-A9 processor (1.5 GHz) |
Memory |
32GB |
Display |
7-inch LCD capacitive touchscreen with 1024 x 600 resolution |
Connectivity |
Mini USB 2.0 USB 2.0 Wi-Fi HDMI Type A Micro SD card (supports up to 32GB) |
Sensors |
Light sensor for brightness auto changing |
Audio input/output |
Input: N/A Output: buzzer |
Power and Battery |
3.7 V/5000 mAh lithium-polymer battery Charges via 5 VDC power supply |
Tested Battery Life |
Around 7 hours of continuous use |
Battery Charging Input |
5 V/1.5 A |
Power Consumption |
600 mA (LCD on with default brightness, Wi-Fi on) @3.7 V |
Operating Temp. |
-10 to 60C(14 to 140F) |
Storage Temp. |
-20 to 70C (-4 to 158F) |
Operating Humidity |
5% - 95% non-condensing |
Dimensions (W x H x D) |
270.8 mm (10.0) x 176.0 mm (6.9) x 36.0 mm (1.4) |
Net Weight |
885 g (2.31 lb.) |
Protocols |
ISO9141-2, ISO14230-2, ISO15765, K/L-Line, Flashing Code, SAE-J1850 VPW, SAE-J1850PWM, ISO11898 (Highspeed, Middlespeed, Lowspeed and Singlewire CAN, fault-tolerant CAN), SAE J2610,GM UART,UART Echo Byte Protocol, Honda Diag-H Protocol, TP2.0, TP1.6 |
Accessories:
1.USB External Power Adapter_test
2.USB Cable (for charging)
3.USB Cable (for test)
4.MaxiVCI Mini
5.User Manual
6.Quick Reference Guide
7.Carry case
8.Magnet
